不锈钢反应釜厂家如何评价呢

不锈钢反应釜厂家Stainless Steel Reactor 一、用途Use 本设备应用于医药、化工、食品、轻工等行业中的水解、中和、结晶、蒸馏、蒸发等生产过程。反应釜可采用304或316L不锈钢材料制造。搅拌形式有锚式框式桨式蜗轮式推进式等;转动机构可采用摆线针轮减速机无级变速减速机等;密封装置可采用机械密封磁力耦合密封;加热冷却可采用夹套半管盘管结构;加热方式有蒸汽电加热导热油等以满足耐酸碱耐高温耐磨损抗腐蚀不同工作环境的工艺需要。可以根据用户工艺要求进行设计制造。选配工艺:可以根据需求做防腐内衬,反应釜内壁防腐喷涂工艺,可以耐强酸强碱高温低温等工艺处理条件。

This equipment is used in production processes such as hydrolysis, neutralization, crystallization, distillation, and evaporation in pharmaceutical, chemical, food, and light industry industries. The reaction kettle can be made of stainless steel materials such as 304 or 316L. The mixing forms include anchor type frame type paddle type worm gear type push type or frame type; The rotating mechanism can adopt cycloidal pin wheel reducer stepless speed reducer etc; The sealing device can adopt mechanical seal magnetic coupling seal; Jacket half tube coil structures can be used for heating and cooling; Heating methods include steam electric heating heat transfer oil etc to meet the process requirements of different working environments such as acid alkali resistance high temperature resistance wear resistance corrosion resistance. Can be designed and manufactured according to user process requirements. Optional process: Anticorrosive lining can be made according to requirements the inner wall of the reaction kettle can undergo anti-corrosion spraying process it can withstand strong acid alkali high temperature low temperature other processing conditions.

二、三不锈钢反应釜厂家结构特点Structural Features ● 反应锅由锅身盖搅拌器电加热油夹套支承及传动装置轴封装置组成可以夹套通导热油循环加热或冷却或夹套设计电热棒或蒸汽半管进行加熱。

The reaction pot is composed of pot body cover agitator electric heating oil jacket support and transmission device shaft seal device etc. the jacket can be heated or cooled by heat transfer oil or jacket design electric heating rod or steam half pipe for heating.

由于用户因生产工艺操作条件不尽相同搅拌形式一般有锚式桨式蜗轮式推进式框架型。

Due to the different operating conditions of users due to the production process the mixing forms generally include anchor paddle worm gear push types frame types.

夹套上开有进排油溢油放空及测温电热棒孔下部开放料口。

The jacket is provided with oil inlet outlet overflow vent and temperature measuring electric heating rod holes lower part open discharge port.

三/Technical Parameter 产品型号Product Model XHSG-5L XHSG-10L XHSG-20L XHSG-30L XHSG-50L XHSG-100L 罐体尺寸CanBody Size Φ219mm Φ250mm Φ300mm Φ350mm Φ400mm φ500 罐体材质CanBody Material 不锈钢304或316 可选

Transmission medium: Heat Transfer Oil

The stirring power:

For small reactors (5 L - 20 L):

Anchor agitator with a power range from 370 W to 550 W

Paddle agitator with a power range from 370 W to 550 W

Worm gear agitator with a power range from

For large reactors (30 L -
